GRATTEN GA1102CAL - Function Introduction and Operation

2
This chapter introduces the functional keys and
operations of the front panel of the series of
oscilloscope in detail.
For effectively using the oscilloscope, the
following functions of the oscilloscope are needed
to be known:
 Menu and control keys
 Connector
 Automatic setup
 Default setup
 “Universal” knob
 Vertical system
 Horizontal system
 Triggering system
 Signal acquisition system
 Display system
 Measurement system
 Save system
 Auxiliary system
 On-line help system
DIGITAL STORAGE OSCILLOSCOPE
Function Introduction
and Operation
