63
2.11 Storage system
[SAVE/RECALL] is a save/recall function key.
Table 2-41 Save type description:
Type Description
Setup save 20 groups of setups can be saved in a format of .SET
Waveform save
16 groups of waveforms can be saved in a format of .DAV
The waveform data can be recalled to the current
oscilloscope or the same series of oscilloscope.
Image save
It is equivalent to screen capture, and the format is .BMP. It
is only saved in a USB flash disc and opened by computer
software.
CSV
The format is .CSV.
It is only saved in a USB flash disc and opened by computer
EXCEL software.
Factory setups
The factory setups are inherent in the oscilloscope when
the oscilloscope leaves factory and are recalled only.
Waveform save: It is waveform data displayed on an interface and can be identified by
the oscilloscope;
The saved image is the whole screen image (including waveform, menu and the like);
The CSV saves the original data points of the waveform.
Save/recall setup
■ Save types
The save types include setup save, waveform save, image save, CSV and factory
setups, wherein the setups and waveforms can be saved and then recalled, the images
and CSV are saved only, and the factory setups are recalled only.
