5. Press the “CurA”option key, and revolve the [UNIVERSAL] knob to place the cursor A
at the highest wave peak of the spike pulse.
6. Press the “CurB”option key, and revolve the [UNIVERSAL] knob to place the cursor B
at the lowest point of the spike pulse.
As shown in figure 3-2，the following measurement results will be displayed on the
display screen:
Voltage increment (peak-to-peak value of the spike pulse) Delta V
Voltage at cursor A
Voltage at cursor B
