99
X-Y mode phase
difference
±3 Degrees
Display type Point display, vector display
Trigger system
Trigger type Edge, pulse, video, slope, alternation
Trigger signal source CH1, CH2, EXT, EXT/5, AC Line
Trigger mode Auto, normal, single
Trigger coupling DC, AC, Low-frequency rejection, high-frequency rejection
Trigger electric level
range
CH1, CH2:±10div
EXT: ±1.5V
EXT/5: ±7.5V
Trigger sensitivity
CH1, CH2: ≤1div
EXT: ≤0.15V
EXT/5: ≤0.75V
Hold-off range 100ns ~10s
Edge trigger Type: rise, descend, rise and descend edge
Pulse width trigger
Type: (>, <, =) positive pulse width
(>, <, =) negative pulse width
Pulse width: 20ns ~ 10s
Pulse width resolution: 5ns or 1‰ (take the higher value)
Video trigger
Support signal system: PAL, NTSC
Trigger condition: odd field, even field, all rows, specified
row
Slope trigger
(>, <, =) positive slope
(>, <, =) negative slope
Time setup: 20ns-10s
Alternating trigger
CH1 trigger type: edge, pulse, video, slope
CH2 trigger type: edge, pulse, video, slope
Measurement system
Automatic
measurement (32
Maximal valve, minimal value, peak-to-peak value,
amplitude, top value, bottom value, periodic average
