GRATTEN GA1102CAL - Appendix B: Default Setup

102
Appendix B : Default setup
Menu or system Option, knob or key
Default setup
Coupling Direct current
Bandwidth limit OFF
Volt/div Coarse tunning
Probe 1×
Inverse phase OFF
Volt/div 200mV
CH1 CH2
Digital filter OFF
Operation CH1+CH2
FFT operation
Signal source CH1
Window Hanning
Horizontal
amplification
1×
MATH
Vertical scale dBVrms
Window Main time base
Position 0.0s
S/div 100μs
HORIZONTAL
Window region time
base
5.0μs
Type OFF
Signal CH1
Voltage ±2 G
CURSOR
Time ±2G
MEASURE Signal source CH1
