GRATTEN GA1102CAL - Page 131

104
Test passed OFF
Waveform recording OFF
RS-232 Baud rate 300
Type Edge
Signal source CH1
Slope Rise
Trigger mode Auto
Coupling Direct current
TRIGGER (EDGE)
Electric level 0.00mV
Type Pulse
Signal source CH1
Condition
Pulse width setup 20.00ns
Trigger mode Auto
TRIGGER
(PULSE)
Coupling Direct current
Type Video
Signal source CH1
Polarity
Synchro All rows
Standard NTSC
TRIGGER
(VIDEO)
Trigger mode Auto
Type Slope
Signal source CH1
TRIGGER
(SLOPE)
Condition
