Coarse tuning
Define a 1-2-5 sequence: 2mv/div,5mv/div,…,5v/div.
Volt/div
Fine tuning Fine tuning changes the resolution as small step in
coarse tuning setup.
1X
10 X
100 X
Probe
1000 X
The coefficient is matched with the attenuation
coefficient of the probe used so as to obtain correct
vertical reading.
Next Page1/2 Press the key to skip to page 2 of the menu.
Table 2-4 Function menu 2 of CH1 and CH2:
Option setup Description
Inverse
Run
Relative to the inverse-phase waveform of a
reference electric level
Stop Stop the waveform inverse function
Digital filter
Press this key to skip to the digital filter menu (seen
in table 2-5).
Back Page2/2 Press the key to get back to page 1 of the menu.
Table 2-5 Digital filtration function menu:
Option Setup Description
Run Run the digital filter
Digital filter
Stop Stop the digital filter
Set the filter as low-pass filter
Set the filter as high-pass filter
Set the filter as band-pass filter
Filter type
Set the filter as band-reject filter
Filter Upper
limit
Set the frequency upper limit using the [UNIVERSAL]
knob
Filter lower Set the frequency lower limit using the [UNIVERSAL]
15
