Installation
14
5 Installation
Read this chapter in its entirety before installing the system
5.1 In General
To avoid possible damage to the equipment or errors in the monitoring readings and alarm
function, it is important to observe the following points carefully:
• The system is not to be used without purge air. Doing so might result in monitoring
errors or equipment failure.
• The transceiver and reflector modules must be placed in areas with low vibration and
with ambient temperatures below 55°C. The location must be suitable for service and
cleaning.
• The transceiver and reflector with air modules are screwed on the welding sockets
welded to the gas uptake in the selected location. The transceiver and reflector must be
properly aligned and mounted firmly and stable direct oppo- site each other. Take con-
sideration of the minimum distance between any walls or construction elements to the
cabinet. Please refer to the system installation layout in the technical drawings to see
the allowed minimum distance.
• The transceiver and reflector must be protected against mechanical damage.
Installation and operation of the G16 Smoke Density Monitor and associated equip-
ment must be carried out by skilled personnel. Green Instruments A/S does not take
any responsibility of the operation of the system and associated equipment whatsoever.
The equipment must only be applied as specified by Green Instruments. If the equip-
ment is used in a manner not specified by Green Instruments, the protection provided
by the equipment may be impaired.
The successful and safe operation of this equipment is dependent upon proper han-
dling, installation, operation, and maintenance.
