GREENLINE 40 - Appendix C: Hybrid Monitor Error Listings; IG Error Listing

Greenline 40 122
APPENDIX C: List of errors displayed by Hybrid monitor
IG ERROR LISTING
IG Error listing (HEX field):
Error Name
HEX
Code
DEC
Code
IG response Reason Remedy Note
No error 0x0000 0 / / /
DC-link
overvoltage
0x0001 01 Error mode
DC-link voltage
is above 270 V
Wait for DC-link
voltage drop
1
Power
module
warm
0x0002 02 Power reduction
IG IGBT module
temperature is above 85°C
Reduce load /
Check HCU
cooling
Power
module
hot
0x0004 03
Increased power
reduction
IG IGBT module
temperature
is above 90°C
Reduce load /
HCU cooling
required
Power
module
excessive
hot
0x0008 04 Error mode
IG IGBT module
temperature
is above 95°C
Stop / HCU
cooling required
Step up
undervoltage
0x0010 05
Electric propulsion
interrupted
Battery voltage dropped
below 42 V
Recharge battery
Bad power
module
0x0020 06 Only error flag signalization
IG IGBT module
temp. sensor failed
Check / replace
IGBT
CAN lost 0x0040 07 Permanent error mode
CAN Communication
with AC part interrupted
Check / replace
HCU
2
Battery
overvoltage
0x0080 08 Error mode
Battery voltage is
above 61 V
Check battery
