Greenline 40 55
Figure 41: Black water outlet position
Figure 42: Black water outlet valve
The capacity of the tank is 80 litres . The indicator will show when the tank is full.
The holding tanks may be flushed. If cleaning is required only use ecologically friendly materials.
System shall be empty during storage at freezing temperatures.
GAS SYSTEM
When changing the cylinder, refit the cap on the pressure reduction valve threaded section to avoid corrosion.
See the Figure XX.
RECOMENDATION!
Don't forget to shut off the gas safety valve and pressure reducing valve when the stove is
not in use.
WATER DISCHARGE
Waste water from the closets is discharged by sea chests, fitted with quarter turn valves (when the valve
handle is perpendicular with the pipe, the valve is closed, and open when along the pipe centerline).
Figure
40
: Black water valve position
