GREENLINE 40 - Toilet Operation; Figure 35: Marine Head with Control Panel and Black Water Gauge

137 pages

Save Page as PDF

To Next Page

To Previous Page

Greenline 40

TOILET OPERATION

Figure 35: Marine head with control panel and black water gauge

CAUTION!

Please do no discharge any black water into the sea within 12Nm from

the shore.

The toilet system is arranged so that the toilets are pumped into a holding tank.
