Maximal power consumption under 230 V wiring system is 7 kW (Shore
power supply + Inverter power boost). If you overload the system the
circuit breaker will trip.
Maximal power consumption under 230 V wiring system through
inverter is 5 kVA (4.5kW). If you overload the system the red light
»overload« on phoenix multi control (on console) will illuminate and the
power will go out. Reduce the consumption!
SHORE POWER
Shore power can be used in the marina. Just connect shore power cable to a marine outlet, (see picture 27)
and turn on fuses QS main, QS AC, QS1 & FS2-FS7 (see chapter »Power sources«). It is recommended to fully
charge the batteries in the marina with shore power!
Picture 27: Shore power cable (230V input) and main fuse
Shore power cable (230 V input), fuse QS main under cockpit seat, stbd side.
