Greenline 40
25
The extinguisher must be located within easy reach and away from possible fire.
Figure 13: Fire extinguishers position
The engine compartment includes a fire port to inject the extinguishing agent without opening the normal
access hatch.
The engine compartment (if your boat is equipped with engine stronger than 120kW) is fitted with fixed
extinguisher with automatically activated control.
Figure 14: Automatic extinguisher piping mounted on engine room hatch
Your dealer shall have to take the pin out of the extinguisher on receiving the boat.
Steps to be taken in case of fire in the engine compartment:
- Stop the engine,
