Greenline 40
83
POWER SOURCES
12V power source:
There is one 12 V socket on console for phone chargers, etc. (Pic. 20). For power supply information see table
2, F12.
Picture 20: 12 V socket on console
230 Vac power source:
230 V circuit is powered from shore cable through Quattro inverter/charger (hybrid only) or directly
(standard). When shore cable is not connected Quattro goes to inverter mode (hybrid only).
There are eight 230 V plugs for house consumers. Four in the salon (kitchen and above stbd locker), two are in
the cabin under bed on port and stbd side, one in guest cabin and one in the toilet. (See Pic. 21-26).
