Greenline 40
59
8. ELECTRICAL SYSTEM
ARRIVING ON THE BOAT
When arriving on the boat you should switch the main switches ON; (Pic.1). If you are planning to stay docked
in the marina or at anchor (A.), it is not necessary to switch ON the propulsion switches, you can switch them
ON before departure (B.)
STAYING AT DOCK OR ANCHOR
A + B. GETTING READY TO SAIL
A - 12 V SERVICE
battery switch (Pic. 1)
A - 24h CONSUMERS
switches (Pic.3)
A - INVERTER ON:
supplies 230V (Pic.4)
B - 12 V ENGINE
battery switches (Pic. 1)
B - BOW THRUSTER
switch in front cabin (Pic. 2)
Picture 1: ENGINE PORT, ENGINE STBD and SERVICE main switch
Picture 2: BOWTHRUSTER (optional) switch in the cabin
