Baserunner V6 User Manual
Rev0
The LED may also flash several different warning codes. These warnings do not
stop the controller from running and will appear as various limits are reached in
normal operation, they are not usually a cause for any concern.
Table 3: LED Warning Flash Codes
5-1 Communication Timeout
5-2 Hall Sensor
5-3 Hall Stall
5-4 Wheel Speed Sensor
5-5 CAN Bus
5-6 Hall Illegal Sector
5-7 Hall Illegal Transition
5-8 Low Voltage Rollback Active
6-1 Max Regen Voltage Rollback Active
6-2 Motor Overtemperature Rollback
6-3 Controller Overtemperature Rollback
6-4 Low SOC Foldback
6-5 Hi SOC Foldback
6-6 I2tFLDBK
6-7 Reserved
6-8 Throttle fault converted to warning
When corresponding with Grin about Baserunner troubleshooting, note in
advance if the LED is flashing when the fault occurs, and include the flash code
in the correspondence.
