10 LED Flash Codes
A small red indicator LED is present on the underside of the controller. This
shines downward through a hole in the controller baseplate and can provide
useful feedback on the controller status. However in some installations the light
is obscured and difficult to see.
It is a useful to examine the LED for troubleshooting any fault behaviors, which
will be communicated by the following flash table. For example, for a 2-4 flash
code, the LED will blink twice in quick succession, followed by a short pause,
then four more blinks, followed by a long pause, at which point the flash code will
repeat. Some faults will clear automatically once the condition clears, such as
“Throttle Voltage Outside of Range,” while other faults may require turning the
controller off and on.
Table 2: LED Fault Flash Codes
1-1 Controller Over Voltage
1-2 Phase Over Current
1-3 Current Sensor Calibration
1-4 Current Sensor Over Current
1-5 Controller Over Temperature
1-6 Motor Hall Sensor Fault
1-7 Controller Under Voltage
1-8 POST Static Gate Test Outside Range
2-1 Network Communications Timeout
2-2 Instantaneous Phase Over Current
2-3 Motor Over Temperature
2-4 Throttle Voltage Outside of Range
2-5 Instantaneous Controller Over Voltage
2-6 Internal Error
2-7 POST Dynamic Gate Test Outside Range
2-8 Instantaneous Controller Under Voltage
3-1 Parameter CRC Error
3-2 Current Scaling Error
3-3 Voltage Scaling Error
3-4 Headlight Under Voltage
3-5 Torque Sensor
3-6 CAN Bus
3-7 Hall Stall
4-1 Parameter2CRC
