C/2-E
Parts List
3A-183A-18
(Revised 1/02)
1 Assembly, Door Front Panel ... 1 133847
2 Screw, #10-32 x .375 Phillips
Flat Head ............................. 8 069723
3 Handle..................................... 1 129723
4 Spacer, Cam ........................... 2 123744
5 Assembly, Cam ....................... 1 074252
6 Screw, #8-32 x 1.00 Phillips
Torx Head Locking ............... 2 123718
7 Screw, #8-32 x .375 Phillips
Torx Head Locking ............... 6 129732
8 Assembly, Door Magnet .......... 1 129726
9 Nut, #10-32 SS ....................... 1 002632
10 Mandrel, Spring....................... 1 130864
11 Spring...................................... 1 078911
12 Spacer, Door Latch ................. 1 094146
13 Weldment, Door Latch
Bracket................................. 1 123572
14 Weldment, Door Inside
Panel.................................... 1 123528
15 Spring, Extension .................... 2 123592
16 Weldment, Retention Clip
Mounting Bracket................. 2 123540
17 Clip, Inner Door Retention ...... 2 123539
18 Assembly, Inner Door.............. 1 123548
19 Gasket, Inner Door.................. 1 123596
20 Bumper, Stem ......................... 6 123588
21 Bracket, Condensate
Deflector............................... 1 138389
22 Screw, #8-32 x .375 Phillips
Flat Undercut Head.............. 6 127178
23 Screw, 1/4-20 x .50 Phillips
Flat Head ............................. 2 123721
24 Hinge, with Mounting Hole ...... 2 123507
25 Assembly, Light Box Cover ..... 1 123570
26 Lamp ....................................... 4 112733
27 Assembly, Light Bar Insulator . 1 123597
28 Screw, #8/32 x .50 Socket
Button Head......................... 2 093255
29 Nut, #8-32 with SEMS............. 2 069784
30 Clip, Fuse 13/32 Dia. S.S. ...... 2 112735
31 Washer, #10 Shoulder............. 1 123866
32 Washer, #10 ............................ 1 014812
33 Nut, #10-32 with SEMS........... 1 071256
34 Weldment, Light Box
Bracket................................. 1 123569
35 Cord, Jumper-Door Light ........ 1 127174
Item Description Qty.
Part
No.
To Next Page
