Groen CC20-E - Bracket Assy 1

CC20-E
Parts List
3-443-443-443-443-443-44
(Revised 1/02)
MOTOR
13
Figure 2. Fan and Motor
1 Bracket Assy . . . . . . . . . . . . . . 1
070100
2 Motor & Heat Stinger Assy.
- 208/240V . . . . . . . . . . . . . .1
081666
2 Motor & Heat Stinger
Assy.
- 480V . . . . . . . . . . . . . . . . . .1
081667
3
Key, 1/8” Square 303 S.S. . . . 1 071288
4 Insulation Retainer Assy. . . . . 1 071228
5 Insulation Nut Plate .. . . . . . . . 1 069770
6 Motor Seal Assy . . . . . . . . . . . 1
071299
• Washer Seal Housing . . . . . 1 070458
• Packing . . . . . . . . . . . . . . . . 3 070459
• Motor Shaft Housing Seal . . 1 070457
7 Washer, Fiber . . . . . . . . . . . . 3 071300
8 Screw, Truss Head S.S. . . . . . 3 081698
9 Wheel Blower Assembly . . . . 1 080681
10 Washer, Flat . . . . . . . . . . . . . . 1 059228
Item Description Qty.
Part
No.
