Groen CC20-E - Drip Tray.

CC10-G
Parts List
4-30
Figure 6. Door, Racks, and Tray
- Door Assembly ........................ 1 See
Fig. 7
2 Control Panel Knob................. 1 073430
3 Shroud Assembly .................... 1 087933
4 Right Side Door Switch ........... 1 078904
5 Middle Rack ............................ 4 069764
6 Drip Tray.................................. 1 070471
7 Left Side Door Switch ............. 1 081621
8 Left Chamber Baffle ................ 1 087932
9 Door Pin Locking Nut .............. 1 003823
10 Door Latch Pin ........................ 1 078914
Item Description Qty.
Part
No.
(Revised 1/02)
