(Revised 1/02)
TROUBLESHOOTING
7-18
PROBLEM: IMPROPER CONDENSATE SPRAY OPERATION - (Continued)
Probable Cause
Corrective Action
No condensate spray. (Continued)
Too much spray.
Continuous spray.
Voltage measured. Replace the relay board.
Voltage not measured between K14 contacts. Continuity
check harness. Replace defective wire and/or wire termi-
nal.
Inspect spray nozzle for damage or wear, and replace
nozzle if necessary
.
Check that incoming water pressure is 30 to 60 psi
(see page 2-1, 3-1, 4-1 or 5-1). If required, take
necessary corrective action.
WARNING
Be sure oven is disconnected from branch
circuit power before performing any repair
work.
NOTICE
For ovens with the Cook and Hold option, the fan
motor will cycle on and off periodically during the
Hold mode.
Place oven in Oven mode. Measure voltage between K14
relay contact terminals.
24VAC measured. Relay K14 is operating properly.
24V
AC not measured.
Refer to relay test page 8-3.
To Next Page
