Groen CC20-E - Page 181

C/2-G
Sequence Of Events
5A-7
Relay Operation Summary
1. K13 and K15 energized.
2. K6 energized.
3. K12 energized.
4. K11 energized.
5. K2 and K3 energized.
6. Relay K13 energized.
7. K11 and K12 de-energized.
8. K3 de-energized and K2 remains energized.
9. K12 energizes.
10. K11 energizes.
11. K14 energizes.
12. K11 and K12 de-energize.
13. K6 energized and de-energized. (cycles)
14. K12 energized.
15. K11 energized.
