SERVICE CODES
6-10
Service Code 2
Table 2 provides information for troubleshooting when on a service call. The
c
olumns list probable causes, replacement parts and special tools needed, and a
page reference to service instructions. Proceed through the Probable Causes in
the sequence shown in the table. If the corresponding Corrective Action does not
correct the problem, proceed to the next Probable Cause and so forth, until the
problem is corrected.
Table 2 - Troubleshooting Service Code 1
Broken lead in Continuity check harness. Replace Digital ohmmeter ————
water level probe water level probe harness if an open
harness. circuit is detected.
Contaminated Clean using a fine emery cloth. ———————— ————
water level probe.
Clean probe holders. Clean holder air ———————— Page 8-12
vent hole for CC10-E unit.
Defective water Replace water level probe. ———————— Page 8-12
level probe.
Relay board and/or
Perform relay board power supply
V
oltmeter
Page 8-3
control panel operation.
check.
Faulty relay board. Replace relay board or flex cable. ———————— Page 8-22
Faulty control panel.
Replace control panel. ———————— Page 8-21
WARNING
Be sure oven is disconnected from branch circuit power before performing any service work.
WARNING
When oven power is turned on, there is high voltage present in the electrical components compartment.
(Revised 1/02)
Service
Reference
LocationProbable Cause
Corrective Action
Test Equipment
