(Revised 1/02)
TROUBLESHOOTING
7-12
PROBLEM: OVEN DOES NOT ACHIEVE READY STATUS - (Continued)
Probable Cause
Corrective Action
Electric Ovens
Water heating element circuit.
CC10-E
Zero current in any water heating.
WARNING
When oven power is turned on, there is high
voltage present in the electrical components
compartment.
Turn on oven power and drain boiler. Begin operation in
Steam mode. Measure current to all water heating
elements (see page 8-9). If boiler is not filling, refer to
service code 3 in the Service Codes section of this manual.
WARNING
Be sure oven is disconnected from branch cir-
cuit power before performing any repair work.
Be sure oven power is off and oven is disconnected
element circuit.
from the power source. Disconnect heat-
ing element from harness and continuity check element.
If water heating element is okay, check harness continuity.
If necessary replace defective wire and/or wire terminal. If
element is an open circuit, replace element, P/N:
208V Unit - 070200
240V Unit - 0721
12
WARNING
When oven power is turned on, there is high
voltage present in the electrical components
compartment.
Connect water heating element to the harness, and turn
on oven power
. Select Steam mode and measure voltage
between contacts of relays K1 through K4.
Zero Volts. Relays are operating correctly.
Voltage reading. Relay is not operating. Replace relay if a
nonactive one is available on the relay board. Nonactive
relays are those without wires connected to them. See
page 8-24.
To Next Page
