Groen CC20-E - Page 24

CC10-E
Electrical Diagrams
After Serial Number C7439MS
2-21
(Revised 1/02)
GND
DB1
L3
BLOCK DISTRIBUTION POWER
208/220/240V
1ø, 3ø
L2
LINE VOLTAGE
L1
-2
MOV
-4
-6
MOV
MOV
-1
MOV
-3
-5
MOV
MOV
MOV BOARD
A6
ELEMENT
AIR
K12B K11B K10B
AH3
K11
RELAY BOARD
K12
K12A
2.25 KW
2.25 KW
K11A
A5
K10
K10A
A1
2.25 KW
A2
AH2
A3
A4
ELEMENT
BOILER
K5B K9B K4B K3B K2B K1B
BH2
3 KW
3 KW
K5A
K9A
K9
K5
K4A
K4
K3
B1
AH1
B3 B2
BH3
K3A
K2 K1
K2A K1A
B6
B4
3 KW
B5
BH1
GND
12AWG
(1ph ONLY)
Xph Yph
SEE TABLE
Schematic Diagrams for CC10-E
