(Revised 1/02)
TROUBLESHOOTING
7-22
PROBLEM: FAN MOTOR DOES NOT OPERATE - (Continued)
Probable Cause
Corrective Action
Relay K6 on relay board may not
be operating properly.
Relay board or control panel problem.
CC10-G and CC20-G (Single Phase Motor)
Relay K6 on relay board may not
be operating properly
.
Check for 24VAC between K6 contacts.
WARNING
Be sure oven is disconnected from branch
circuit power before performing any repair
work.
24VAC measured.
Turn off oven power and check K6
relay coil continuity (see schematic diagram, page 3-33).
Open circuit measured. Replace the relay board.
Coil has continuity. Refer to schematic diagram (page
3-33) and continuity check wiring harness. Replace defec-
tive wire and/or wire terminal.
Perform relay board power supply check. See page 8-3.
WARNING
When oven power is turned on, there is high
voltage present in the electrical components
compartment.
Check for 1
15VAC between K6 contacts.
115VAC measured. Turn off oven power and check K6
relay coil continuity
.
To Next Page
