Maintenance
Replacement Procedures
8-25
(Revised 1/02)
Relay Board
Installation
(
continued)
6. Correctly connect leads 11131 (5) and RB2 (6).
7. Connect door switch leads to terminals (3 and 4).
8. Connect relay board harness (2) to control panel.
9. Check for continuity to ground at ground pad (11).
10. Correctly connect relay wires to relays (1).
11. Connect oven to the branch circuit and operate oven. Check that all touch pad
and status lights are illuminated for the selected mode of operation.
12. Install right side panel.
