Maintenance
Replacement Procedures
8-36
Door Pin (Bullet)
1. Turn off oven power.
2. Allow oven to cool.
3. Note and record distance between jam nut and end of bullet. This
information will be needed in step 6.
4. Loosen jam nut, then remove door bullet and jam nut.
5. Coat bullet threads with a high temperature (1800°F) anti-seize and
lubricating compound.
6. Install bullet and jam nut. The jam nut-to-end of bullet distance should
be approximately the same as measured in step 3.
(Revised 1/02)
