(Revised 1/02)
C/2-E
Specifications
3A-1
Oven Electrical Specifications
Water Line Pressure
30 to 60 PSIG. A pressure regulator is required for water pressure above
60 PSIG.
Drain Connection
With Drain Box:
1. Drain hose to a building drain can be connected directly.
2. The drain box has an air vent that eliminates the need for an air gap.
3. Do not block the air vent in any way.
4. Do not attach anything to the vent tube or reduce the size of the
vent tube.
65.4A
56.7A
28.3A
Power
21KW
21KW
21KW
AC Input
Voltage
280V, 3-Phase
240V, 3-Phase
480V, 3-Phase
Current Rating
Per Line
