C/2-E
Sequence Of Events
3A-5
10. Relay K6 and R1 energize and de-energize, cycling the fan motor on for 10
seconds and off for 30 seconds.
11. When the oven cavity cools down to the hold set point temperature, relays
K11, K12, R11 and R12 energize and de-energize to maintain the cavity
temperature.
Relay Operation Summary
1. K13 and K15 energized.
2. K6 and R1 energized.
3. K11, K12, R11 and R12 energized.
4. K2, K3, R2 and R3 energized. K11, K12, R11 and R12 de-energized.
5. K13 de-energized.
6. K3 and R3 de-energized. K2 and R2 energized.
7. Relay K14 energized.
8. K11, K12, R11 and R12 energized.
9. K11, K12, R11 and R12 de-energized.
10. K6 and R1 energize and de-energize.
11. K11, K12, R11 and R12 energize and de-energize.
(Revised 1/02)
