3.6.2 Start Checkweighing
The checkweigh applications do not have a start function. Simply put the item to be weighed onto the scale
platter. An annunciator will illuminate to indicate whether the item is within tolerance.
3.6.2.1 Annunciators
In order for the annunciators to activate, the displayed value must be at least five graduations above zero.
Status Annunciator Status Annunciator Color
(LED)
OVER SP 1 Illuminated
Red
GOOD SP 2 Illuminated
Green
UNDER SP 3 Illuminated
Yellow
3.7 Fill
The fill program is used for single-speed or dual-speed filling operations. The dual-speed fill operation allows
for both a fast and a slow fill mode. During a fast-fill, setpoints 1 (SP1) and 2 (SP2) are activated. During a
slow-fill or single-speed fill, only setpoint 1 (SP1) is activated. This feature must be enabled before
attempting to use. Over filling can be prevented with the use of pre-act values (PA1 and PA2). Pre-act 1
(PA1) is used for switching the fast fill to a slow fill. Pre-act 2 (PA2) is used as a final cutoff value.
3.7.1 Enter a Target Value
Pressing 1 or ( alone allows access to the subsets. PA1 and PA2 are the subsets for Targ 1.
3.7.1.1 Model 350
1. Press ! until tArG1 is displayed.
2. Press
 until the first digit of the new target is displayed. Press 2 to accept the number displayed.
Continue this step until the desired number is entered. Refer to the example below.
Example: Target of 20
Press
 four times
DISPLAY READS X 2
Press
2 to accept the 2 that is displayed
DISPLAY READS X 2 .
Press
 once
DISPLAY READS X 20
Press
1 to accept the target weight as 20
DISPLAY READS X 20
3. Press
1. Once the tare key is pressed, it is possible that PA1 will be displayed if the pre-act parameter
is enabled.
If a value is desired, enter it in the same manner as the target weight was entered above. When the
displayed value is correct, press
1.
