GSE 355 - 3.11.2 Start Checkweighing; 3.11.3 Absolute Checkweighing Example

AWT35‐500349|June2009 Page24
3.11.2.1 Annunciators
In order for the annunciators to activate, the displayed value must be at least five graduations above zero.
Status Annunciator Status Annunciator Color
(LED)
OVER SP 1 Illuminated
Red
GOOD SP 2 Illuminated
Green
UNDER SP 3 Illuminated
Yellow
3.11.3 Absolute Checkweighing Example
With a system set up to check-weigh 50 lb. cement bags, the following settings might be used check-weigh
bag from 49.5 to 51.5 lbs.:
Parameter Setting Acceptable Values Comments
Target = 50.00 Desired bag weight.
Low Value = 49.50 0 - 49.50 lbs. Low acceptable range = 0 to 49.50 lbs.
Target Window 49.50 – 51.50 lbs Good light within this range
High Value = 51.50 51.50 lbs. and above High acceptable range = 51.50 lbs. and above
3.12 Target Deviation Checkweigh
The target deviation method uses a target value in which the upper and lower tolerances are deviated from
the target. The upper and lower tolerances are fixed values. The accept window is varied by adding the high
tolerance to the target and subtracting the low tolerance from the target. This feature is commonly used in
check-weigh applications. The desired target may be based on gross weight, net weight or quantity (if
counting is enabled). The annunciators will light on the indicator display or physical setpoints can be added.
This feature must be enabled before attempting to use.
3.12.1 Enter a Target Value
3.12.1.1 Model 350
1. Press ! until tArG1 is displayed. The target value will need to be entered. Go to step 2.
2. Press
 until the first digit of the new target is displayed. Press 2 to accept the number displayed.
Continue this step until the desired number is entered.
Example: Target of 20
Press
 four times
DISPLAY READS X 2
Press
2 to accept the 2 that is displayed
DISPLAY READS X 2 .
Press
 once
DISPLAY READS X 20
Press
1 to accept the target weight as 20
