GSE 355 - 4.0 Troubleshooting; 4.1 Operational Errors; 4.2 Miscellaneous Errors

AWT35‐500349|June2009 Page29
4.3 Hardware Errors
Code00
An EPROM problem detected during power up.
A-D ~ Bad!
Or Code17
Problem with A/D chip detected. Disconnect any options installed and re-power the
unit. Options are connected to the same serial lines as the A/D so they may prevent
it from working properly.
Deflt ~ A-D
Bad A/D calibration values.
Re- ~ Boot!
EEPROM data could not be read. Attempting power-up reset.
Code21~E2rd
Error while reading data from EEPROM.
Code21~E2sd
Error while saving data to EEPROM.
Deflt ~ Setup
An error occurred when reading setup data from the EEPROM during power-up. All
parameters are set to factory default.
Ch.XXXX
A checksum error occurred during power-up. All annunciators are lit. The EPROM
integrity test failed or is improperly seated.
E2 ~ Full!
The EEPROM setup exceeds the memory capacity.
NoSpc ~ Free!
The current setup exceeds the setup RAM capacity.
4.4 Communication Errors
Par-Er
The selected parity does not match that of the connected device.
Buf-Er
The receive buffers capacity was exceeded. This indicates a handshaking problem.
Bit-Er
The stop bit of a received character did not occur when expected.
Trans~Hold1
Data transmission is inhibited due to a deasserted handshake on communication port 1.
Press
" or  to abort transmission.
Trans~Hold2
Data transmission is inhibited due to a deasserted handshake on communication port 2.
Press
" or  to abort transmission.
Error~BaudX
The X being either comm port 1 or comm. port 2. The baud rate selected is too high for
the microprocessor rate.
