GSE 355 - 3.9 Discharge; 3.9.1 Enter a Target

AWT35‐500349|June2009 Page19
3.9 Discharge
The discharge program is designed for single-speed or dual-speed dispensing of product from a larger weigh
vessel. Discharge is a loss-in-weight application similar in operation to the fill program. When a discharge is
initiated, the scale automatically tares and comes to a net zero weight. The appropriate setpoints are
activated and material is discharged until the decreasing net weight reaches the desired target value. Free
falling product can be accounted for with the use of pre-act values (PA1 – PA3). This feature must be
enabled before attempting to use.
3.9.1 Enter a Target
3.9.1.1 Model 350
1. Press ! until tArG1 is displayed.
2. Press
 until the first digit of the new target is displayed. Press 2 to accept the number displayed.
Continue this step until the desired number is entered.
Example: Target of 20
Press
 four times
DISPLAY READS X 2
Press
2 to accept the 2 that is displayed
DISPLAY READS X 2 .
Press
 once
DISPLAY READS X 20
Press
1 to accept the target weight as 20
DISPLAY READS X 20
3. Press
1. Once the tare key is pressed, it is possible that PA1 will be displayed if the pre-act parameter
is enabled.
If a value is desired, enter it in the same manner as the target weight was entered above. When the
displayed value is correct, press
1.
If no value is to be entered or PA1 is not displayed, press
1 to go to the next screen.
4. Repeat steps 2 and 3 until all targets and pre-acts are entered.
5. Press
1 to return to the weigh mode.
3.9.1.2 Model 355
1. Press ! until tArG1 is displayed.
2. Key in the desired target value with the numeric keys and press
(.
3. The PA1 value will be displayed. Key the in value with the numeric keys and press
(.
4. Repeat steps 2 and 3 until all targets and pre-acts are entered.
5. Press
! to select the desired weigh mode parameter.
