3.13 Batch 2
The batch 2 program is used for batching up to three separate items without using pre-act values.
Ingredients 1 through 3 use setpoints 1 through 3 respectively. Ingredients are batched one at a time. The
target values can only be set from the weigh mode by pressing the
! key.
After a batch is run all target values will be set back to 0. The target values will be set to 0 after accessing
the setup mode or if power is cycled. If a new batch is started when all target values are set to 0 an error
message “No Targ” will be displayed. This feature must be enabled before attempting to use.
3.13.1 Enter a Target
3.13.1.1 Model 350
1. Press ! until tArG1 is displayed.
2. Press
 until the first digit of the new target is displayed. Press 2 to accept the number displayed.
Continue this step until the desired number is entered.
Example: Target of 20
Press
 four times
DISPLAY READS X 2
Press
2 to accept the 2 that is displayed
DISPLAY READS X 2 .
Press
 once
DISPLAY READS X 20
Press
1 to accept the target weight as 20
DISPLAY READS X 20
3. If more than one target is enabled, press
! to advance to the next target (e.g. tArG2). Repeat steps 2
and 3 until all values are entered.
3.13.1.2 Model 355
1. Press ! until tArG1 is displayed.
2. Key in the target weight with the numeric keys and press
(.
3. If more than one target is enabled, press
! to advance to the next target (e.g. tArG2). Repeat steps 2
and 3 until all values are entered.
3.13.2 Activation Method
The filling of each ingredient begins when one of three selectable start functions occur. Each ingredient may
have its own start function. The deactivation of the setpoint is automatic. The desired targets may be based
on net weight or quantity (if counting is enabled).
