3.10 Fill and Discharge
The ‘Fill and Discharge’ program combines a fill operation with a discharge operation. This automates a
single-speed vessel filling operation with a single-speed multiple dispensing function. Setpoint 1 is used for
filling the vessel and Setpoint 2 is used for product discharge. Free falling product can be accounted for with
the use of pre-act values (PA1 and PA2). This feature must be enabled before attempting to use.
3.10.1 Enter a Target
3.10.1.1 Model 350
1. Press ! until tArG1 is displayed.
2. Press
 until the first digit of the new target is displayed. Press 2 to accept the number displayed.
Continue this step until the desired number is entered.
Example: Target of 20
Press
 four times
DISPLAY READS X 2
Press
2 to accept the 2 that is displayed
DISPLAY READS X 2 .
Press
 once
DISPLAY READS X 20
Press
1 to accept the target weight as 20
DISPLAY READS X 20
3. Press
1. Once the tare key is pressed, it is possible that PA1 will be displayed if the pre-act parameter
is enabled.
If a value is desired, enter it in the same manner as the target weight was entered above. When the
displayed value is correct, press
1.
If no value is to be entered or PA1 is not displayed, press
1 to go to the next screen.
4. Repeat steps 2 and 3 until all targets and pre-acts are entered. Press
1 to return to the weigh mode.
3.10.1.2 Model 355
1. Press ! until tArG1 is displayed.
2. Key in the desired target value with the numeric keys and press
(.
3. The PA1 value will be displayed. Key the in value with the numeric keys and press
(.
4. Repeat steps 2 and 3 until all targets and pre-acts are entered.
5. Press
! to select the desired weigh mode parameter.
3.10.2 Pre-acts
Pre-act 1 is used for vessel filling. Pre-act 1 specifies the point where the final cutoff for the fill should occur.
Pre-act 2 specifies the point where the final cutoff for the material discharge should occur.
