3. Specifications and Dimensions
16 PNEG-1156ETL Design III Series Grain Stir-Ator CSA
Design III Stir-Ator Overall Dimensions (Continued)
(See Figure 3A on Page 15.)
**18' and 18' 7'' Bin diameter available on DA only.
NOTE: 1. DA frame rails up to 36' are 4'' x 3'' x 1/4''
2. DA frame rails 36' to 48' are 5'' x 3'' x 5/16''
3. TA frame rails are 5'' x 3'' x 5/16''
Bin Diameter Dimension “A” DA Dimension “A” TA
Dimension “B”
DA and TA
Dimension “C”
DA and TA
**18' 40-1/8" NA 114-1/2" 113"
**18' 7'' 43-5/8" NA 118" 116-1/2"
2
21' 58-1/8" 40-1/8" 132-1/2" 131"
21' 7'' 61-5/8" 43-5/8" 136" 134-1/2"
22' 64-1/8" 46-1/8" 138-1/2" 137"
22' 9'' 68-5/8" 50-5/8" 143" 141-1/2"
24' 76-1/8" 58-1/8" 150-1/2" 149"
2
24' 3'' 77-5/8" 59-5/8" 152" 150-1/2"
24' 8'' 80-1/8" 62-1/8" 154-1/2" 153"
27' 94-1/8" 76-1/8" 168-1/2" 167"
27' 10'' 99-1/8" 81-1/8" 173-1/2" 172"
28' 100-1/8" 82-1/8" 174-1/2" 173"
28' 3'' 101-5/8" 83-5/8" 176" 174-1/2"
30' 112-1/8" 94-1/8" 186-1/2" 185"
31' 118-1/8" 100-1/8" 192-1/2" 191"
33' 130-1/8" 112-1/8" 204-1/2" 203"
36' 148-1/8" 130-1/8" 222-1/2" 221"
36' 3'' 149-5/8" 131-5/8" 224" 222-1/2"
39' 166-1/8" 148-1/8" 240-1/2" 239"
40' 172-1/8" 154-1/8" 246-1/2" 245"
42' 184-1/8" 166-1/8" 258-1/2" 257"
48' 220-1/8" 202-1/8" 294-1/2" 293"
