6. Parts List
PNEG-1156ETL Design III Series Grain Stir-Ator CSA 57
Design III Stir-Ator Track Unit Parts List (Continued)
Ref # Part # Description Double Auger Triple Auger
143 106C038 Outboard Frame End 1 1
145 106C046 Cord Clip 22
146 106C048-XXXX Right Frame Rail (Single) 14' to 48' (Specify Bin Diameter) 0 0
147 106C049-XXXX Left Frame Rail (Single) 14' to 48' (Specify Bin Diameter) 0 0
148 106C055-XXXX Right Frame Rail (Double) 18' to 36' (Specify Bin Diameter) 1 0
149 106C056-XXXX Left Frame Rail (Double) 18' to 36' (Specify Bin Diameter) 1 0
150 106C058-XXXX Right Frame Rail (Triple) 21' to 36' (Specify Bin Diameter) 0 1
151 106C059-XXXX Left Frame Rail (Triple) 21' to 36' (Specify Bin Diameter) 0 1
152 106C061-XXXX Right Frame Rail (Double-Triple) 36' to 48' 1 1
153 106C062-XXXX Left Frame Rail (Double-Triple) 36' to 48' 1 1
154 106C063 Track Bracket 8-1/2" A/R A/R
206 502A0045 Gear Motor (440 Volt) (No Longer Used - See Page 70)11
207 DMC20087 Gear Motor (230 Volt) 1 1
226 PT0883 Flanged Bronze Bushing, 1-1/4" O.D. x 1" I.D. x 3/4" 4 4
227 PT0888-D Case Bronze Bushing, 1-3/4" O.D. x 1-1/2" I.D. x 1-3/8" Long 1 1
230 PT1098 Roller Chain Sprocket, #40-10T w/ 3/4" Bore Standard - Under 36' 1 1
231 PT1099 Roller Chain Sprocket, #40-12T w/ 3/4" Bore, Offset - Under 36' Standard 36' and Over 1 1
232 PT1101 Roller Chain Sprocket, #40-14T w/ 3/4" Bore, Offset - 36' and Over 1 1
246 105E0101 Bottom, 4 x 4 Electrical Box, PVC 1 1
247 FH-1310 Connector, Cord Heyco #3231 7 8
254 1EL0561 Butt Splice Wire Connector 2 2
257 105E0105 Fuse, FRZ, 2A 250V Midget TD Fuse 2 2
300 S-6781 Nylon Wing Nut, 1/4" 1 1
303 S-4310 Hex Lock Nut, 1/4" 14 16
304 S-5220 Hex Lock Nut, 5/16" 6 9
308 S-396 Hex Nut, 5/16" A/R A/R
309 S-456 Hex Nut, 3/8" A/R A/R
328 S-8059 Carriage Bolt, 5/16" x 1" A/R A/R
329 S-3585 Carriage Bolt, 3/8" x 1" 22 26
330 S-9094 Carriage Bolt, 5/16" x 3", Full Thread, Grade 5 A/R A/R
335 S-1101 Hex Bolt, 1/4" x 1/2" 3 3
338 S-7520
Hex Bolt, 3/8" x 1"
1-1/2 HP 4 4
2 HP 12 16
354 3FH0574 Heavy External Retaining Ring, 1" 2 2
362 3FH0790 Lock Washer, 5/16" A/R A/R
363 S-1054 Lock Washer, 3/8" A/R A/R
365 3FH0817 Bushing, 7/8" O.D. x 33/64" I.D. x 10 Gauge 1 1
368 3FH0831 Machinery Bushing, 1-1/2" O.D. x 1" I.D. x 14 Gauge 2 2
372 3FH0898 Spring Pin, 1/4" x 2" 1 1
374 3FH0948 Flat Washer, 3/8" SAE 8 10
379 3FH0977 Round Cupped Washer, 7/8" O.D. x 5/16" I.D. A/R A/R
380 3FH0986 Woodruf Key, 3/16" x 5/8" 1 1
