6. Parts List
PNEG-1156ETL Design III Series Grain Stir-Ator CSA 61
Design III Stir-Ator Yoke Parts List
Ref # Part # Description Double Auger Triple Auger
1 103A0003 Junction Box Cover 2 2
2 103A0049 12'' Pulley with Drive Link 1 0
4 103A0069 End Yoke Idler 2 2
5 103A0070 Cable Tube 1 1
19 103E0012 Insulating Washer, 1/16'' 1 1
26 104A0014 Center Pivot Flanged Bushing 1 1
27 104A0015 Center Pivot Thrust Bearing 1 1
31 104E0001 Electric Swivel Insulating Block 6 6
32 104E0007 Ring and Wire (White) 1 1
33 104E0010 Ring and Wire (Black) 1 1
34 104E0012 Ring and Wire (Green) 1 1
35 104E0015 Ring and Wire (Red, 3 Phase Only) 1 1
36 104E0020
Electrical Swivel Contact Strap
1 Phase 33
3 Phase 4 4
43 104E2005 Electric Swivel Assembly, 230 Volt, 3 Phase 1 1
49 105A0030 Center Drive Arm and Shaft 1 1
52 105A0053 Support Yoke Spacer tube (36' Diameter Bin and Larger Only) 1 1
55 105A0097
Swivel Spring Clip
1 Phase 33
3 Phase 4 4
56 105A0101 14'' Pulley w/ Drive Link (Triple) 0 1
57 105A0201 Junction Box, Swivel - Weldment 1 1
66 105E0004 Electric Swivel Assembly, 230 Volt, 1 Phase 1 1
73
DAVID0973-
DAVID1078
Yoke (Single-Double) (Specify Bin Diameter) 1 0
74
DAVID1079-
DAVID1087
Yoke (Triple) (Specify Bin Diameter) 0 1
75 106A040 End Yoke 1 1
76 106A042 Cable Adjustment 1 1
77 106A048 Yoke Wire Support (39' Diameter Bin and Under Only) 1 1
78 106A049 Yoke Wire Support Spring 1 1
79 106A050 Cable Connector 1 1
80 106A051 Cable, 3/16'' (Specify Bin Diameter) 1 1
81 106A052 Swivel Box Cover 2 2
82 106A056 Neoprene Sponge Plug 1 1
83 106A059 Center Yoke Support (Single-Double) (36' Diameter Bin and Larger Only) 1 0
84 106A060 Center Yoke Support (Triple) (36' Diameter Bin and Larger Only) 0 1
85 106A064 Yoke Support (39' 1'' Diameter Bin and Larger Only) 1 1
144 106C042 Inboard Frame End 1 1
146 106C048-XXXX Right Frame Rail (Single) 14' to 48' (Specify Bin Diameter) 0 0
147 106C049-XXXX Left Frame Rail (Single) 14' to 48' (Specify Bin Diameter) 0 0
148 106C055-XXXX Right Frame Rail (Double) 18' to 36' (Specify Bin Diameter) 1 0
149 106C056-XXXX Left Frame Rail (Double) 18' to 36' (Specify Bin Diameter) 1 0
150 106C058-XXXX Right Frame Rail (Triple) 21' to 36' (Specify Bin Diameter) 0 1
