PNEG-1156ETL Design III Series Grain Stir-Ator CSA 67
Design III Stir-Ator Double and Triple Auger Trolley Parts List (Continued)
Ref # Part # Description Double Auger Triple Auger
130 106B198 10'' Pulley Spacer 2 3
140 106C035 3/8'' x 1-1/4'' Shoulder Bolt 6 8
160 106E205 Bracket - Right Junction Box Assembly CSA 1 0
161 106E207 Bracket - Left Junction Box Assembly CSA 1 1
162 106E120 Bracket Terminal Block, CSA 1 1
193 1EL3105 Box, Steel Nema 12, DA 1 1
214 PT0222 1-3/8'' Precision Bearing w/ Eccentric Locking Collar 4 6
216 PT0377 Radial Ball Bearing, 17 mm (36' Diameter Bin and Larger Only) 10 10
217 PT0408 1-3/8'' Eccentric Locking Collar 4 6
219 PT0428 2 Hole Stamped Flangette 8 12
220 PT0489 AX-48 V-Belt (1-1/2 HP Only) 2 3
221 GK1952 B-50 V-Belt (2 HP 1842 Motor Frame Size) 2 3
222 PT0621 Pulley, 3-1/4'' O.D. x 7/8'', 1 Grade, B Sec, 2 HP, w/ Set Screw (105B0076) 2 3
223 PT0625 Pulley, 3'' O.D. x 1-3/8'', B Sec, w/ Set Screw 2 3
224 PT0670 Pulley, 10" O.D. x 1-3/8", B Sec, w/ Set Screw 2 3
247 1EL0410 Adapter, Connector - AL. 1 MPT A/R A/R
248
KD-PEE0067 Strain Relief 1" NPT x 3/4" O.D. âTâ and B #2546 1" NPT STR Strain Relief 2 2
1EL0431 Cord Connector, 1'' NPT 2 2
267 1EL0887 Terminal Block - 3 Post - Double Row - 1 Phase 1 1
268 1EL0888 Terminal Block - 4 Post - Double Row - 3 Phase 1 1
272 1EL2046
Rubber Grommet, 1'' O.D. x 9/16'' I.D. x 5/16'' (Not Used on Offset Trolley)
6 9
273 1EL0428 Cord Connector, 3/4" 1 1
274 D03-0247 Cable Tie, 1-1/4'' A/R A/R
281 106E208 Switch, Electronic Tilt - Assembly, CSA 1 1
288 3EL5098 Motor, TEFC, 1-1/2 HP, 1 Phase, 230 Volt 2 3
289 3EL5100 Motor, TEFC, 1-1/2 HP, 3 Phase, 220/440 Volt 2 3
290 3EL5109 Motor, 2 HP, 3 Phase, 220/440 Volt 2 3
291 3EL5110 Motor, TEFC, 2 HP, 1 Phase, 115/230 Volt 2 3
301 S-4198 Wing Nut, 1/4'' 1 1
303 S-4310 Hex Lock Nut, 1/4'' 32 38
306 S-8315 Lock Nut 1/2"-13 ZN GRC Prevailing Torque 2 2
308 S-3611 Flange Nuts 5/16''-18 YDP Grade 2 A/R A/R
310 S-8133 Hex Nut, 1/2'', Fine Thread 4 6
318 2FH0405 U-Bolt, 1/4'' x 3/4'' x 1-1/4'' 4 6
320 2FH0427 Wiring Thumb Screw, 1/4'' x 5/8'' 2 3
322 2FH0450 Button Head Cap Screw, 1/2'' x 1-3/4'' 1 1
323 S-8794 Slotted Hex Washer Head Self-Tapping Screw, #10 x 1/2'', Type F 7 7
326 S-6369 Carriage Bolt, 1/4'' x 3/4'' 1 1
327 S-6076 Carriage Bolt, 5/16'' x 3/4'' A/R A/R
329 S-3585 Carriage Bolt, 3/8'' x 1'' 22 26
337 S-853 Hex Bolt, 1/4'' x 1-1/2'' 1 1
338 S-7520
Hex Bolt, 3/8'' x 1''
1-1/2 HP 4 4
2 HP 12 16
343 S-8087 Flange Bolt, 1/4"-20 x 5/8" ZN 19 23
344 S-8088 Hex Bolt, 1/2'' x 2-1/2'', Grade 5, Fine Thread 4 6
355 3FH0577 External Retaining Ring, 1-3/8'' (Not Used On Offset Trolley) 2 3
357 S-7443 Pin Hairpin Cotter 0.080 Wire Diameter x 1-3/16'' Overall 2 3
359 S-7825 Pin Hairpin Cotter 1/8 Wire Diameter x 2-1/2'' Overall 9 10
360 S-8094 Cotter Pin, 1/4'' x 1-3/4'' 2 2
To Next Page
