GSi DMC Design III Series User Manual

6. Parts List
66 PNEG-1156ETL Design III Series Grain Stir-Ator CSA
Design III Stir-Ator Double and Triple Auger Trolley Parts List
Ref # Part # Description Double Auger Triple Auger
7 103B0012 Mercury Switch Holder Bracket 1 1
8 103B0015 16' Plain Auger 2 3
9 103B0016 16' Hard-Surfaced Auger 2 3
58 105B0076 5/16'' x 3/8'' Set Screw with Adhesive 2 3
59 105B0079 18' Regular Auger 2 3
60 105B0080 20' Regular Auger 2 3
61 105B0081 21' Regular Auger 2 3
62 105B0082 18' Hard-Surfaced Auger 2 3
63 105B0083 20' Hard-Surfaced Auger 2 3
64 105B0084 21' Hard-Surfaced Auger 2 3
92 106B044 Motor Mount Plate 2 3
93 106B045 Shield Support Bracket 2 3
94 106B046 Motor Tension Removal Rod 2 3
95 106B049 Motor Spring Guide Rod 2 3
98 106B053 Upper Angle Bracket (Double) 1 0
99 106B054 Lower Angle Bracket (Double) 1 0
100 106B055 Upper Angle Bracket (Triple) 0 1
101 106B056 Lower Angle Bracket (Triple) 0 1
103 106B066 Trolley Body (Double) 1 0
104 106B067 Trolley Body (Triple) 0 1
106 106B079 Hold-Down Rod 2 2
108 106B081 Trolley Stub Shaft 2 3
109 106B083 Trolley Wheel 4 6
110 106B085 Axle Shield Support Bracket 1 1
111 106B088
Upper Roller Support Bracket
36' Diameter Bin and Larger (Single-Double) 1 0
27' 1'' Diameter Bin and Larger (Triple) 0 1
112 106B091
Long Roller Stand-Off
36' Diameter Bin and Larger (Single-Double) 2 0
27' 1'' Diameter Bin and Larger (Triple) 0 2
113 106B093 Roller and Shield Support Bracket (Double-Triple) 1 2
114 106B095
Roller Support Bracket Assembly
36' Diameter Bin and Larger (Single-Double) 2 0
27' 1'' Diameter Bin and Larger (Triple) 0 2
115 106B096
Roller Support Bracket
36' Diameter Bin and Larger (Single-Double) 2 0
27' 1'' Diameter Bin and Larger (Triple) 0 2
116 106B097
Short Roller Stand-Off
36' Diameter Bin and Larger (Single-Double) 8 0
27' 1'' Diameter Bin and Larger (Triple) 0 8
117 106B098 Tension Removal Link 2 3
118 106B099 Trolley Belt Shield 2 3
119 106B100 Trolley Compression Spring 2 3
120 106B102 Drive Arm Post 1 1
121 106B103 Drive Arm 1 1
122 106B110 Stand-Off Bushing 1 1
124 106B115 Leveling Disc (Not Used on Offset Trolley) 4 6
125 106B118 Auger Clamp 2 3
128 106B124 Auger Clamp with Spring Pin Assembly 2 3
129 106B125 Auger Clamp with Spring Pin Hole 2 3
