GSi Q112 User Manual

Chapter 6: Installing the Wet Bin
Table 6-1 Part descriptions of the dryer wet bin
Callout
Part
Number
Description
Qua-
ntity
1
Dryer wet bin hardware package
1
2
D01-0465
Turnbuckle, 0.50 in. X 6 in.
1
3 & 4 D01-1182-Y
Top auger belt guard assembly (includes #3, #4, and #5)
1
3
D01-0452-
Y
Top auger belt guard cover (not shown)
1
4 D01-0453
Top auger belt guard body
1
5
Belt guard assembly mounting hardware (see Table 6-2, page 47)
6 D01-0044
Top angle bracket, front and rear
2
7 D01-0156
Top auger housing channel
2
8 D01-1526
Wet bin end plate connector
4
9 D01-0155
Belt guard mounting bracket
1
10 NA
Motor shaft sheave (determined by the dryer model)
1
11 D01-0464 Belts BX97 2
12 D32-0019
Bushing Q1 - 1.50 in. split taper (for auger shaft sheave and includes
hardware)
1
13 D52-0001
Sheave, 16 in. grip-belt 2 groove
1
14
D01-0193-
Y
Hopper assembly
1
Table 6-2 Hardware packages for the belt guard of the dryer wet bin
Part
number
Description
Quantity
S-6501 3/8 in. - 16 X 4 in. bolt 3
S-968
3/8 in. - 16 flange whiz nut
9
S-248 3/8 in. flat washer 4
S-6606
5/16 in. - 18 X 3/4 in. flange bolt
3
S-3611
5/16 in. - 18 flange nut
3
S-3949 3/8 in. - 16 X 1 in. bolt 2
S-4663
3/8 in. - 16 locking nut
2
PNEG–2088 Quiet Portable Dryer
47
