GST102A/GST104A/GST108A/GST116A
Conventional Fire Alarm Control Panel
Installation and Operation Manual
Page 12
FAULT1 FAULT2 FAULT3 FAULT4 FAULT5 FAULT6 FAULT7 FAULT8
ALARM1 ALARM2 ALARM3 ALARM4 ALARM5 ALARM6 ALARM7 ALARM8
Fig. 1-9
FAULT1~FAULT8: Fault output terminals for zone 1 to 8.
ALARM1~ALARM8: Alarm output terminals for zone 1 to 8.
