3.10 Restore Default Settings
The basic features of the default settings are as follows:
 Every zone is set “With Manual Call Point”.
 When there is fire alarm from any zone, all sounder outputs will be started, and these outputs
will be continuous and not be delayed.
 The alarm output is not set with delay time.
 All zones and sounder outputs are not disabled.
A quick way to restore default settings as follows:
1 Enter access level III.
2 Pressing the OUTPUT PROGRAM button for at least 2 seconds, the CIE gives 1 second sound
indication to indicate a successful reset to factory settings.
3 Exit access level III.
3.11 Default DIP Switch Settings
Label Setting
Alarm output N/O
Sounder 1 Output Voltage
Aux Power
Jumper pins on AUX + 24 for continuous
voltage
Ground Fault connected
Level 3 1 off
MCP zone 2 off
Alarm output 3 off
sounder output 4 off
sounder mode 5 off
resound mode 6 off
sil-reset mode 7 off
sil-delay mode 8 off
Delay time 1 1 off
Delay time 2 2 off
Delay time 3 3 off
Delay time 4 4 off
test zone out 5 off
dis/sup. Out 6 off
Relay output 7 off
reserve use 8 off
SW3
Location
X1
X2
X3
X6
SW2
