3.5.3 Setting Delay Time of Alarm Output
Delay time of alarm output can be set through the following steps.
1 Enter access level III.
2 Set the “3” of SW2 (ALARM OUTPUT) to ON position.
3 Pressing the OUTPUT PROGRAM button, the OUTPUT PROGRAM LED illuminates steadily
and ALARM OUTPUT FAULT LED flashes to show the CIE enters delay time setup. The
FAULT LED will indicate according to the CIE fault condition. Other indicators, except for the
above mentioned LEDs, will be turned off.
4 The Dip switches “1” to “4” of SW3 (DELAY TIME) are used for setting the delay time of the
selected Sounder Output from 0-150 seconds, refer to Table 3-8.
5 Pressing the ENTER button saves the current setting. The CIE will sound for 1 second to
indicate the successful setup.
6 Pressing the CANCEL button will exit alarm output delay time setup and the OUTPUT
PROGRAM LED will be turned off.
7 Set the “3” of SW2 (ALARM OUTPUT) and “1” to “4” of SW3 (DELAY TIME) to OFF position.
8 Exit access level III.
☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆
Note: If you want to enable the delay function, you must first cancel the "with manual call Point"
setting in the zone.
☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆☆
3.5.4 Sounder Output Mode
Instead of all of the sounder outputs activating at the same time you are able to program certain
sounder outputs to activate when a particular zone/s are activated. This type of programming is
rarely used. Default setting is Immediate Output. Please refer to the below table (3-6) when for
additional information.
Table 3-6
Mode
Description
DISABLE/ENABLE
LED
TEST LED
1
No output
OFF
OFF
2
Output after alarm output activated
OFF
ON
3
Delay output (refer table 3-8 to set time)
ON
OFF
4
Immediate output (Default)
ON
ON
