GUDEL PR - Black Screws; Table 12-2 Torque Table for Black Oiled and Non-Lubricated Screws

12.1.2 Black screws
Unless otherwise specified, the following tightening torques apply for black
oiled and non-lubricated screws, or screws secured with Loctite 243:
Thread size Tightening torque [Nm]
8.8 10.9 12.9
M4 3 4.6 5.1
M5 5.9 8.6 10
M6 10.1 14.9 17.4
M8 24.6 36.1 42.2
M10 48 71 83
M12 84 123 144
M14 133 195 229
M16 206 302 354
M20 415 592 692
M22 567 804 945
M24 714 1017 1190
M27 1050 1496 1750
M30 1420 2033 2380
M36 2482 3535 4136
Table12-2 Torque table for black oiled and non-lubricated screws
Torque tables SERVICE MANUAL Güdel planetary gear NR, SR, PR
