GUDEL PR - Fig. 5 -1 Attaching Slings; Fig. 5 -2 Packaging Symbols

5.1 Packaging symbols
When moving the transport pallets / crates / cases, observe the following
symbols:
CENTER OF
GRAVITY
D003601
SLING
HERE
SLING
HERE
D003600
A B
Fig.5-1 Attaching slings
A Center of gravity
B Fastening point
Depending on the contents, the packaging units are marked with the symbols
shown below. Observe these at all times.
FRAGILE
D000098
D000099
CRAINT L'HUMIDITE
D000100
HANDLE
WITH CARE
D000101
A B C D
Fig.5-2 Packaging symbols
A Fragile C Keep dry
B This side up D Handle with care
