GUDEL PR - Gearbox; Table 7-4 Inspection Table

Inspection
point
Description Measures
Contamination Check the planetary
gear for contamination
Immediately clean away any
contamination
Damage Check the planetary
gear for damage:
• Paint damage
• Bent components
• General damage
Immediately remedy all dis-
covered damage
Loose compo-
nents
Check the fit of the
components:
• Screws
• Clamping sets
Immediately tighten loose
screws to the required
torque
Loss of oil Check the planetary
gear and its surround-
ings for signs of the fol-
lowing:
• Puddles of oil and oil
spills on the floor or
in the drip sheets
• Leaks on the plane-
tary gear
• Repair or replace the
gearbox
• Remove puddles of oil
and oil spills on the floor
or in the drip sheets
Setting Check the planetary
gear for correct setting:
• Pinions
Set the tooth flank backlash
Table7-4 Inspection table
