7.2.3 Maintenance tasks after 150 hours
7.2.3.1 Lubricating the pinion
If available, lubricate the pinion after 150 operating hours or 100 km. Lubri-
cate several times if tribocorrosion (reddish discoloration) occurs.
CAUTION
Danger of being crushed
When performing work on the product, there is a risk of being crushed in
the area around the exposed pinions.
Observe the following points:
• Never reach into the area around the pinions
• Use a brush to apply the lubrication to the pinions
D003856
Lubrication ex
works
Specification Lubrication quantity
Mobil Mobilux EP 2 KP2K-30 in accordance
with DIN 51502
Table7-3 Lubricants: Pinion
MaintenanceSERVICE MANUAL Güdel planetary gear NR, SR, PR
9007199543219723_v1.1_EN-US
47
