12.1.3 Stainless steel screws
Unless otherwise specified, the following tightening torques apply for stainless
steel screws lubricated with Molykote (MoS2) grease or secured with Loctite
243:
Thread size Tightening torque [Nm]
50 70 80
M3 0.37 0.8 1.1
M4 0.86 1.85 2.4
M5 1.6 3.6 4.8
M6 2.9 6.3 8.4
M8 7.1 15.2 20.3
M10 14 30 39
M12 24 51 68
M14 38 82 109
M16 58 126 168
M20 115 247 330
M22 157 337 450
M24 198 426 568
M27 292 — —
M30 397 — —
M36 690 — —
Table12-3 Torque table for stainless steel screws lubricated with Molykote (MoS2) grease
